1. Math library

1.1. Class Inheritance diagram

1.2. openalea.plantgl.math module

class Matrix2

IDENTITY = Matrix2( 1, 0 ,          0, 1 )

adjoint((Matrix2)arg1) → Matrix2 :

C++ signature :

PGL::Matrix2 adjoint(PGL::Matrix2)

data((Matrix2)arg1) → list :

C++ signature :

boost::python::list data(PGL::Matrix2)

det((Matrix2)arg1) → float :

C++ signature :

double det(PGL::Matrix2)

getColumn((Matrix2)arg1, (object)arg2) → Vector2 :

C++ signature :

PGL::Vector2 getColumn(PGL::Matrix2 {lvalue},unsigned char)

getDiagonal((Matrix2)arg1) → Vector2 :

C++ signature :

PGL::Vector2 getDiagonal(PGL::Matrix2 {lvalue})

getRow((Matrix2)arg1, (object)arg2) → Vector2 :

C++ signature :

PGL::Vector2 getRow(PGL::Matrix2 {lvalue},unsigned char)

inverse((Matrix2)arg1) → Matrix2 :

C++ signature :

PGL::Matrix2 inverse(PGL::Matrix2)

isOrthogonal((Matrix2)arg1) → bool :

C++ signature :

bool isOrthogonal(PGL::Matrix2 {lvalue})

isSingular((Matrix2)arg1) → bool :

C++ signature :

bool isSingular(PGL::Matrix2 {lvalue})

isValid((Matrix2)arg1) → bool :

C++ signature :

bool isValid(PGL::Matrix2 {lvalue})

static linearTransformation((Vector2)i1, (Vector2)j1, (Vector2)i2, (Vector2)j2) → Matrix2 :

C++ signature :

PGL::Matrix2 linearTransformation(PGL::Vector2,PGL::Vector2,PGL::Vector2,PGL::Vector2)

static rotation((object)angle) → Matrix2 :

C++ signature :

PGL::Matrix2 rotation(double)

svd((Matrix2)arg1) → object :

Singular Value Decomposition of a Matrix2. Return rotation matrix and the two singular values.

C++ signature :

boost::python::api::object svd(PGL::Matrix2)

trace((Matrix2)arg1) → float :

C++ signature :

double trace(PGL::Matrix2)

transpose((Matrix2)arg1) → Matrix2 :

C++ signature :

PGL::Matrix2 transpose(PGL::Matrix2)

class Matrix3

IDENTITY = Matrix3( 1, 0, 0 ,          0, 1, 0 ,          0, 0, 1 )

adjoint((Matrix3)arg1) → Matrix3 :

C++ signature :

PGL::Matrix3 adjoint(PGL::Matrix3)

static axisRotation((Vector3)arg1, (object)arg2) → Matrix3 :

C++ signature :

PGL::Matrix3 axisRotation(PGL::Vector3,double)

data((Matrix3)arg1) → list :

C++ signature :

boost::python::list data(PGL::Matrix3)

det((Matrix3)arg1) → float :

C++ signature :

double det(PGL::Matrix3)

eulerAnglesXYZ((Matrix3)arg1) → Vector3 :

C++ signature :

PGL::Vector3 eulerAnglesXYZ(PGL::Matrix3 {lvalue})

eulerAnglesZYX((Matrix3)arg1) → Vector3 :

C++ signature :

PGL::Vector3 eulerAnglesZYX(PGL::Matrix3 {lvalue})

static eulerRotationXYZ((Vector3)arg1) → Matrix3 :

C++ signature :

PGL::Matrix3 eulerRotationXYZ(PGL::Vector3)

static eulerRotationZYX((Vector3)arg1) → Matrix3 :

C++ signature :

PGL::Matrix3 eulerRotationZYX(PGL::Vector3)

getColumn((Matrix3)arg1, (object)arg2) → Vector3 :

C++ signature :

PGL::Vector3 getColumn(PGL::Matrix3 {lvalue},unsigned char)

getDiagonal((Matrix3)arg1) → Vector3 :

C++ signature :

PGL::Vector3 getDiagonal(PGL::Matrix3 {lvalue})

getRow((Matrix3)arg1, (object)arg2) → Vector3 :

C++ signature :

PGL::Vector3 getRow(PGL::Matrix3 {lvalue},unsigned char)

inverse((Matrix3)arg1) → Matrix3 :

C++ signature :

PGL::Matrix3 inverse(PGL::Matrix3)

isOrthogonal((Matrix3)arg1) → bool :

C++ signature :

bool isOrthogonal(PGL::Matrix3 {lvalue})

isSingular((Matrix3)arg1) → bool :

C++ signature :

bool isSingular(PGL::Matrix3 {lvalue})

isValid((Matrix3)arg1) → bool :

C++ signature :

bool isValid(PGL::Matrix3 {lvalue})

static scaling((Vector3)arg1) → Matrix3 :

C++ signature :

PGL::Matrix3 scaling(PGL::Vector3)

scaling( (object)arg1) -> Matrix3 :

C++ signature :

PGL::Matrix3 scaling(double)

toAxisAngle((Matrix3)arg1) → object :

C++ signature :

boost::python::api::object toAxisAngle(PGL::Matrix3 const*)

trace((Matrix3)arg1) → float :

C++ signature :

double trace(PGL::Matrix3)

transpose((Matrix3)arg1) → Matrix3 :

C++ signature :

PGL::Matrix3 transpose(PGL::Matrix3)

class Matrix4

IDENTITY = Matrix4( 1, 0, 0, 0 ,          0, 1, 0, 0 ,          0, 0, 1, 0 ,          0, 0, 0, 1 )

adjoint((Matrix4)arg1) → Matrix4 :

C++ signature :

PGL::Matrix4 adjoint(PGL::Matrix4)

data((Matrix4)arg1) → list :

C++ signature :

boost::python::list data(PGL::Matrix4)

det((Matrix4)arg1) → float :

C++ signature :

double det(PGL::Matrix4)

getColumn((Matrix4)arg1, (object)arg2) → Vector4 :

C++ signature :

PGL::Vector4 getColumn(PGL::Matrix4 {lvalue},unsigned char)

getDiagonal((Matrix4)arg1) → Vector4 :

C++ signature :

PGL::Vector4 getDiagonal(PGL::Matrix4 {lvalue})

getRow((Matrix4)arg1, (object)arg2) → Vector4 :

C++ signature :

PGL::Vector4 getRow(PGL::Matrix4 {lvalue},unsigned char)

getTransformation((Matrix4)arg1) → tuple :

Return scaling, rotation and translation corresponding the decomposition of the matrix into R(rotate) * S(scale) + T(translate) where R( rotate=(az,ay,ax) ) is the product of 3 matrices Rz(az)Ry(ay)Rx(ax)

C++ signature :

boost::python::tuple getTransformation(PGL::Matrix4*)

getTransformation2((Matrix4)arg1) → tuple :

Return scaling, rotation and translation corresponding the decomposition of the matrix into S(scale) * R(rotate) + T(translate) where R( rotate=(az,ay,ax) ) is the product of 3 matrices Rz(az)Ry(ay)Rx(ax)

C++ signature :

boost::python::tuple getTransformation2(PGL::Matrix4*)

getTransformationB((Matrix4)arg1) → tuple :

Alternative method to getTransformation.

C++ signature :

boost::python::tuple getTransformationB(PGL::Matrix4*)

inverse((Matrix4)arg1) → Matrix4 :

C++ signature :

PGL::Matrix4 inverse(PGL::Matrix4)

isOrthogonal((Matrix4)arg1) → bool :

C++ signature :

bool isOrthogonal(PGL::Matrix4 {lvalue})

isSingular((Matrix4)arg1) → bool :

C++ signature :

bool isSingular(PGL::Matrix4 {lvalue})

isValid((Matrix4)arg1) → bool :

C++ signature :

bool isValid(PGL::Matrix4 {lvalue})

set((Matrix4)arg1, (tuple)arg2) → None :

C++ signature :

void set(PGL::Matrix4 {lvalue},boost::python::tuple)

setTransformation((Matrix4)arg1, (Vector3)arg2, (Vector3)arg3, (Vector3)arg4) → None :

C++ signature :

void setTransformation(PGL::Matrix4 {lvalue},PGL::Vector3,PGL::Vector3,PGL::Vector3)

setTransformation2((Matrix4)arg1, (Vector3)arg2, (Vector3)arg3, (Vector3)arg4) → None :

C++ signature :

void setTransformation2(PGL::Matrix4 {lvalue},PGL::Vector3,PGL::Vector3,PGL::Vector3)

trace((Matrix4)arg1) → float :

C++ signature :

double trace(PGL::Matrix4)

static translation((Vector3)arg1) → Matrix4 :

C++ signature :

PGL::Matrix4 translation(PGL::Vector3)

transpose((Matrix4)arg1) → Matrix4 :

C++ signature :

PGL::Matrix4 transpose(PGL::Matrix4)

class Vector2

ORIGIN = Vector2(0,0)

OX = Vector2(1,0)

OY = Vector2(0,1)

class Polar

isValid((Polar)arg1) → bool :

Returns whether self is valid.

C++ signature :

bool isValid(PGL::Vector2::Polar {lvalue})

property radius

property theta

cwiseProduct((Vector2)arg1, (Vector2)arg2) → Vector2 :

component wise product.

C++ signature :

PGL::Vector2 cwiseProduct(PGL::Vector2 {lvalue},PGL::Vector2)

getMaxAbsCoord((Vector2)arg1) → int :

Returns the index of the maximum absolute coordinate.

C++ signature :

int getMaxAbsCoord(PGL::Vector2 {lvalue})

getMinAbsCoord((Vector2)arg1) → int :

Returns the index of the minimum absolute coordinate.

C++ signature :

int getMinAbsCoord(PGL::Vector2 {lvalue})

isNormalized((Vector2)arg1) → bool :

Returns whether self is normalized.

C++ signature :

bool isNormalized(PGL::Vector2 {lvalue})

isOrthogonalTo((Vector2)arg1, (Vector2)v) → bool :

Returns whether self is orthogonal to v.

C++ signature :

bool isOrthogonalTo(PGL::Vector2 {lvalue},PGL::Vector2)

isValid((Vector2)arg1) → bool :

Returns whether self is valid.

C++ signature :

bool isValid(PGL::Vector2 {lvalue})

normalize((Vector2)arg1) → float :

Normalizes self and returns the norm before.

C++ signature :

double normalize(PGL::Vector2 {lvalue})

normed((Vector2)arg1) → Vector2 :

Return a normed version of self.

C++ signature :

PGL::Vector2 normed(PGL::Vector2 {lvalue})

property x

property y

class Vector3

class Cylindrical

isValid((Cylindrical)arg1) → bool :

Returns whether self is valid.

C++ signature :

bool isValid(PGL::Vector3::Cylindrical {lvalue})

property radius

property theta

property z

ORIGIN = Vector3(0,0,0)

OX = Vector3(1,0,0)

OY = Vector3(0,1,0)

OZ = Vector3(0,0,1)

class Spherical

isValid((Spherical)arg1) → bool :

Returns whether self is valid.

C++ signature :

bool isValid(PGL::Vector3::Spherical {lvalue})

property phi

property radius

spherical_distance((Spherical)arg1, (object)arg2, (object)arg3) → float :

C++ signature :

double spherical_distance(PGL::Vector3::Spherical {lvalue},double,double)

property theta

anOrthogonalVector((Vector3)arg1) → Vector3 :

C++ signature :

PGL::Vector3 anOrthogonalVector(PGL::Vector3 {lvalue})

anisotropicNorm((Vector3)arg1, (Vector3)arg2) → float :

C++ signature :

double anisotropicNorm(PGL::Vector3,PGL::Vector3)

cwiseProduct((Vector3)arg1, (Vector3)arg2) → Vector3 :

component wise product.

C++ signature :

PGL::Vector3 cwiseProduct(PGL::Vector3 {lvalue},PGL::Vector3)

getMaxAbsCoord((Vector3)arg1) → int :

Returns the index of the maximum absolute coordinate.

C++ signature :

int getMaxAbsCoord(PGL::Vector3 {lvalue})

getMinAbsCoord((Vector3)arg1) → int :

Returns the index of the minimum absolute coordinate.

C++ signature :

int getMinAbsCoord(PGL::Vector3 {lvalue})

isNormalized((Vector3)arg1) → bool :

Returns whether self is normalized.

C++ signature :

bool isNormalized(PGL::Vector3 {lvalue})

isOrthogonalTo((Vector3)arg1, (Vector3)v) → bool :

Returns whether self is orthogonal to v.

C++ signature :

bool isOrthogonalTo(PGL::Vector3 {lvalue},PGL::Vector3)

isValid((Vector3)arg1) → bool :

Returns whether self is valid.

C++ signature :

bool isValid(PGL::Vector3 {lvalue})

normalize((Vector3)arg1) → float :

Normalizes self and returns the norm before.

C++ signature :

double normalize(PGL::Vector3 {lvalue})

normed((Vector3)arg1) → Vector3 :

Return a normed version of self.

C++ signature :

PGL::Vector3 normed(PGL::Vector3 {lvalue})

project((Vector3)arg1) → Vector2 :

C++ signature :

PGL::Vector2 project(PGL::Vector3 {lvalue})

radialAnisotropicNorm((Vector3)arg1, (Vector3)arg2, (object)arg3, (object)arg4) → float :

C++ signature :

double radialAnisotropicNorm(PGL::Vector3,PGL::Vector3,double,double)

reflect((Vector3)arg1, (Vector3)arg2) → Vector3 :

C++ signature :

PGL::Vector3 reflect(PGL::Vector3 {lvalue},PGL::Vector3)

refract((Vector3)arg1, (Vector3)arg2, (object)arg3) → Vector3 :

C++ signature :

PGL::Vector3 refract(PGL::Vector3 {lvalue},PGL::Vector3,double)

property x

property y

property z

class Vector4

ORIGIN = Vector4(0,0,0,0)

OW = Vector4(0,0,0,1)

OX = Vector4(1,0,0,0)

OY = Vector4(0,1,0,0)

OZ = Vector4(0,0,1,0)

cwiseProduct((Vector4)arg1, (Vector4)arg2) → Vector4 :

component wise product.

C++ signature :

PGL::Vector4 cwiseProduct(PGL::Vector4 {lvalue},PGL::Vector4)

getMaxAbsCoord((Vector4)arg1) → int :

Returns the index of the maximum absolute coordinate.

C++ signature :

int getMaxAbsCoord(PGL::Vector4 {lvalue})

getMinAbsCoord((Vector4)arg1) → int :

Returns the index of the minimum absolute coordinate.

C++ signature :

int getMinAbsCoord(PGL::Vector4 {lvalue})

isNormalized((Vector4)arg1) → bool :

Returns whether self is normalized.

C++ signature :

bool isNormalized(PGL::Vector4 {lvalue})

isOrthogonalTo((Vector4)arg1, (Vector4)v) → bool :

Returns whether self is orthogonal to v.

C++ signature :

bool isOrthogonalTo(PGL::Vector4 {lvalue},PGL::Vector4)

isValid((Vector4)arg1) → bool :

Returns whether self is valid.

C++ signature :

bool isValid(PGL::Vector4 {lvalue})

normalize((Vector4)arg1) → float :

Normalizes self and returns the norm before.

C++ signature :

double normalize(PGL::Vector4 {lvalue})

normed((Vector4)arg1) → Vector4 :

Return a normed version of self.

C++ signature :

PGL::Vector4 normed(PGL::Vector4 {lvalue})

project((Vector4)arg1) → Vector3 :

C++ signature :

PGL::Vector3 project(PGL::Vector4 {lvalue})

property w

wtoxyz((Vector4)arg1) → Vector4 :

C++ signature :

PGL::Vector4 wtoxyz(PGL::Vector4 {lvalue})

property x

property y

property z

angle((Vector2)v1, (Vector2)v2) → float :

The angle between v1 and v2

C++ signature :

double angle(PGL::Vector2,PGL::Vector2)

angle( (Vector3)v1, (Vector3)v2) -> float :

The angle between v1 and v2

C++ signature :

double angle(PGL::Vector3,PGL::Vector3)

angle( (Vector3)v1, (Vector3)v2, (Vector3)axis) -> float :

The angle around axis between v1 and v2

C++ signature :

double angle(PGL::Vector3,PGL::Vector3,PGL::Vector3)

axisRotation((Vector3)arg1, (object)arg2) → Matrix3 :

C++ signature :

PGL::Matrix3 axisRotation(PGL::Vector3,double)

cross((Vector2)v1, (Vector2)v2) → float :

The cross product of v1 and v2

C++ signature :

double cross(PGL::Vector2,PGL::Vector2)

cross( (Vector3)v1, (Vector3)v2) -> Vector3 :

The cross product of v1 and v2

C++ signature :

PGL::Vector3 cross(PGL::Vector3,PGL::Vector3)

cross( (Vector3)v1, (Vector3)v2) -> Vector3 :

The cross product of v1 and v2

C++ signature :

PGL::Vector3 cross(PGL::Vector3,PGL::Vector3)

direction((object)v) → object :

The direction of the vector. Resulting vector is normed. If v.__direction__() exists, call it.

C++ signature :

boost::python::api::object direction(boost::python::api::object)

dot((object)v1, (object)v2) → float :

The dot product of v1 and v2

C++ signature :

double dot(boost::python::api::object,boost::python::api::object)

eulerRotationXYZ((Vector3)arg1) → Matrix3 :

C++ signature :

PGL::Matrix3 eulerRotationXYZ(PGL::Vector3)

eulerRotationZYX((Vector3)arg1) → Matrix3 :

C++ signature :

PGL::Matrix3 eulerRotationZYX(PGL::Vector3)

norm((object)v) → object :

The norm of the vector. If v.__norm__() exists, call it.

C++ signature :

boost::python::api::object norm(boost::python::api::object)

norm( (object)arg1, (object)arg2 [, (object)arg3 [, (object)arg4 [, (object)arg5 [, (object)arg6 [, (object)arg7 [, (object)arg8 [, (object)arg9 [, (object)arg10 [, (object)arg11 [, (object)arg12 [, (object)arg13 [, (object)arg14 [, (object)arg15]]]]]]]]]]]]]) -> float :

C++ signature :

double norm(double,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double]]]]]]]]]]]]])

normL1((object)v) → object :

The L1 (Manhattan) norm of the vector. If v.__normL1__() exists, call it.

C++ signature :

boost::python::api::object normL1(boost::python::api::object)

normL1( (object)arg1, (object)arg2 [, (object)arg3 [, (object)arg4 [, (object)arg5 [, (object)arg6 [, (object)arg7 [, (object)arg8 [, (object)arg9 [, (object)arg10 [, (object)arg11 [, (object)arg12 [, (object)arg13 [, (object)arg14 [, (object)arg15]]]]]]]]]]]]]) -> float :

C++ signature :

double normL1(double,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double]]]]]]]]]]]]])

normLinf((object)v) → object :

The L-infinite norm of the vector. If v.__normLinf__() exists, call it.

C++ signature :

boost::python::api::object normLinf(boost::python::api::object)

normLinf( (object)arg1, (object)arg2 [, (object)arg3 [, (object)arg4 [, (object)arg5 [, (object)arg6 [, (object)arg7 [, (object)arg8 [, (object)arg9 [, (object)arg10 [, (object)arg11 [, (object)arg12 [, (object)arg13 [, (object)arg14 [, (object)arg15]]]]]]]]]]]]]) -> float :

C++ signature :

double normLinf(double,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double]]]]]]]]]]]]])

normSquared((object)v) → object :

The square of the norm of the vector. If v.__normSquared__() exists, call it.

C++ signature :

boost::python::api::object normSquared(boost::python::api::object)

normSquared( (object)arg1, (object)arg2 [, (object)arg3 [, (object)arg4 [, (object)arg5 [, (object)arg6 [, (object)arg7 [, (object)arg8 [, (object)arg9 [, (object)arg10 [, (object)arg11 [, (object)arg12 [, (object)arg13 [, (object)arg14 [, (object)arg15]]]]]]]]]]]]]) -> float :

C++ signature :

double normSquared(double,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double [,double]]]]]]]]]]]]])

scaling((Vector3)arg1) → Matrix3 :

C++ signature :

PGL::Matrix3 scaling(PGL::Vector3)

spherical_distance((object)theta1, (object)phi1, (object)theta2, (object)phi2, (object)radius) → float :

The distance on a unit sphere of the 2 directions given by v1 and v2

C++ signature :

double spherical_distance(double,double,double,double,double)

strain((Matrix2)transformation) → Matrix2 :

Return the engineering strain associated to the transformation

C++ signature :

PGL::Matrix2 strain(PGL::Matrix2)

strain( (Vector2)i1, (Vector2)j1, (Vector2)i2, (Vector2)j2) -> Matrix2 :

C++ signature :

PGL::Matrix2 strain(PGL::Vector2,PGL::Vector2,PGL::Vector2,PGL::Vector2)

stress((Matrix2)strain, (Matrix3)material) → Matrix2 :

Return the stress associated to a given strain using Hook’s law

C++ signature :

PGL::Matrix2 stress(PGL::Matrix2,PGL::Matrix3)
